App Plugins

Use plugins to enhance the iAdvize interface by adding or editing predefined features.

Plugins are basically HTTP endpoints whose json responses fit the plugin json-schema. For each plugin one or more endpoint have to be defined. When a plugin is used on user interface, we will make a GET http call to endpoint with documented query parameters. Your http response have to comply with plugin json-schema. You can find a link of the json schema below each plugin route. It can be used to validate your http responses on your side.

The plugins already available are:

• The product List (on the discussion panel)

• The customer information (on the discussion panel)

• The conversation closing form (on the discussion panel) - only for Chat/Call/Video channels

• The bot (add an external bot within iadvize chatbox)

Product list

The integration of the product list enables iAdvize's Console panel users to browse a product catalog from the iAdvize discussion panel. Agents can look for a product while they are chatting and send it in just a click within their conversation.

Products are displayed in a popup window just over the conversations view: When shared, visitors can see their image, title, availability and price. By clicking on the "view product" button, visitors are redirected to the product page on your website.

Product list

Add the Product list plugin

To make sure your connector uses the Product list plugin correctly, all you have to do is to declare:

• The product list URL - this is your catalog’s URL

• The categories url - this is where your connector will get the list of your product categories

Categories data

Request - GET method

Query parameter	Description	Values
idConnectorVersion	Connector version id	?idConnectorVersion=c008849d-7cb1-40ca-9503-d6df2c5cddd8
idParent	Unique identifier of the parent category	?idParent=123
idWebsite	Unique identifier of the website on which your connector is installed	?idWebsite=ha-123
idOperator	Unique identifier of the operator loading the categories	?idOperator=9999
limit	Maximum number of resources per page	?limit=10
offset	Number of resources skipped before beginning to return resources	?offset=10

Response - Array of categories

[
    {
        "id": "123",
        "idParent": "123",
        "label": "category",
        "products": [
            "123",
            "456"
        ],
        "productsCount": 3
    },
    {
        "id": "456",
        "idParent": null,
        "label": "category",
        "products": null,
        "productsCount": 7
    }
 ]

Field	Description	Values	Required
id	Unique identifier	Integer	✓
idParent	Unique identifier of the parent category	Integer
label	Label	String	✓
products	products	Array of strings
productsCount	Number of products	Integer	✓

You can validate your response data format with the associated json schema

Products data

Request - GET method

Query parameter	Description	Values
idConnectorVersion	Connector version id	?idConnectorVersion=c008849d-7cb1-40ca-9503-d6df2c5cddd8
idCategory	Category id	?idCategory=123
idWebsite	Unique identifier of the website on which your connector is installed	?idWebsite=ha-123
idOperator	Unique identifier of the operator loading the products	?idOperator=9999
limit	Maximum number of resources per page	?limit=10
offset	Number of resources skipped before beginning to return resources	?offset=10
searchQuery	Product search query	?searchQuery=query

Response - Array of products

[
    {
        "id": "123",
        "title": "Product's title",
        "productUrl": "http://www.e-commerce.com/url-product",
        "brand": "brand",
        "description": "product's description",
        "shortDescription": "shrot description",
        "available": true,
        "imageUrl": "http://www.e-commerce.com/url-product-image.jpg",
        "reference": "reference",
        "priceCatalog": "99.9 €",
        "pricePromotion": "90 €",
        "priceSpecial": "80 €"
    },
    {
        "id": "456",
        "title": "Product's title",
        "productUrl": "http://www.e-commerce.com/url-product",
        "brand": null,
        "description": "product's description",
        "shortDescription": null,
        "available": true,
        "imageUrl": "http://www.e-commerce.com/url-product-image.jpg",
        "reference": null,
        "priceCatalog": "9.9 €",
        "pricePromotion": null,
        "priceSpecial": null
    }
]

Field	Description	Values	Required
id	Unique identifier	Integer	✓
title	Title	String	✓
productUrl	Product's url	String	✓
brand	Brand	String
description	Description	String	✓
shortDescription	Short description	String
available	Availability	Boolean
imageUrl	Image's url	String	✓
reference	Reference	String	✓
priceCatalog	Price catalog	String	✓
pricePromotion	Price promotion	String
priceSpecial	Price special	String

You can validate your response data format with the associated json schema.

Customer information

The customer information plugin enables iAdvize's Console panel users to access to customer information in a single click. Agents can overview the customer information in a new window while they are chatting. Operators can then edit it or simply look for information.

To be able to retrieve the customer information, iAdvize must be able to identify the visitor thanks to an email and/or an external ID.

Customer information

Add the customer information plugin In order to set the right plugin parameters, all you have to do is to declare:

• The customer information URL - this is your customer information URL (mandatory).

• The customer information action URL - This URL will be triggered, if agent click on ACTION type field. This field is not mandatory.

Customer information data

Request - GET method

Query parameter	Description	Values
emailVisitor	Visitor email	?emailVisitor=[e-mail]
idConnectorVersion	Connector version id	?idConnectorVersion=c008849d-7cb1-40ca-9503-d6df2c5cddd8
idVisitorExternal	Visitor external id	?idVisitorExternal=123
idVisitorUnique	Visitor unique id	?idVisitorUnique=a7b94266db827c5b8f04586e8e543abd4b7e976e9a723
idWebsite	Unique identifier of the website on which your connector is installed	?idWebsite=ha-123
operatorLocale	Operator locale	?operatorLocale=en
idOperator	Unique identifier of the operator loading the visitor profile	?idOperator=9999

Response - Array of fields

[
    {
        "id":"crm_profile_link",
        "label": "CRM profile",
        "value": "https://www.crm.fr/customer-information",
        "fieldType":"URL"
    },
    {
        "id":"crm_visitor_tag",
        "label": "CRM tag",
        "value": "tag",
        "fieldType": "TEXT"
    },
    {
        "id":"crm_create_case_action",
        "label": "Create a case",
        "value": "OPEN_CASE",
        "fieldType": "ACTION"
    }
]

Field	Description	Values	Required
id	Unique identifier	String	✓
label	Label	String	✓
value	Value	String	✓
fieldType	Field type	ACTION, TEXT or URL	✓

You can validate your response data format with the associated json schema.

Customer information action URL

Request - POST method

Body parameters	Description	Values
action	Action to execute on the connector	OPEN_CASE
idConnectorVersion	Connector version id	c008849d-7cb1-40ca-9503-d6df2c5cddd8
idVisitorUnique	Visitor unique id	a7b94266db827c5b8f04586e8e543abd4b7e976e9a723
idWebsite	Unique identifier of the website on which your connector is installed	ha-123
idConversation	Identifier of the current conversation	ha-123
idOperator	Operator identifier who has clicked on the action	ha-12345

Response - Array of fields

{
    "success": true,
    "message": "Case created with success"
}

Field	Description	Values	Required
success	Result of the action	Boolean	✓
message	Result message of the action	String

You can validate your response data format with the associated json schema.

Conversation closing form

The conversation closing form plugin enables iAdvize's Console panel users to provide additional information manually at the end of conversation. This plugin is only available for Chat / Call and Video channels. 3rd part channels are not supported.

Conversation closing form plugin

Add the conversation closing form plugin

In order to set the right plugin parameters, all you have to do is to declare:

• The connector URL - this is your form's url

Conversation Closing Form data

Request - GET method

Query parameter	Description	Values
idConnectorVersion	Connector version id	?idConnectorVersion=c008849d-7cb1-40ca-9503-d6df2c5cddd8
idWebsite	Unique identifier of the associated website (assigned to you by iAdvize)	?idWebsite=ha-123
operatorLocale	Operator locale	?operatorLocale=en
idOperator	Unique identifier of the operator loading the form	?idOperator=9999

Response - Array of inputs

Field	Description	Values	Required
id	Unique identifier	string	✓
idParent	Parent identifier, if the field depends on it	string
label	Label	string	✓
fieldType	Field type	TEXT, CHECKBOX, SELECT, TEXTAREA, INTEGER or DECIMAL	✓
isRequired	Required	Boolean	✓
options	List of options object for SELECT type	array
options.label	Label displayed for this option	string	✓
options.value	Value saved when option is selected	string	✓

[
    {
        "id": "create_crm_ticket",
        "label": "Create a CRM ticket",
        "fieldType": "CHECKBOX",
        "isRequired": true
    },
    {
        "id": "brand_name",
        "label": "Brand name",
        "fieldType": "TEXT",
        "isRequired": true
    },
    {
        "id": "brand_description",
        "label": "Brand name brings a totally new concept \n to their customers.",
        "fieldType": "TEXTAREA",
        "isRequired": true
    },
    {
        "id": "ticket_priority",
        "idParent": "create_crm_ticket",
        "label": "Priority",
        "fieldType": "SELECT",
        "isRequired": true,
        "options": [
            {
                "label": "Major",
                "value": "MAJOR"
            },
            {
                "label": "Minor",
                "value": "MINOR"
            },
            {
                "label": "Trivial",
                "value": "TRIVIAL"
            }
        ]
    },
    {
        "id": "order_id",
        "label": "The order id related to the claim",
        "fieldType": "INTEGER",
        "isRequired": false
    },
    {
        "id": "order_discount",
        "label": "The discount granted to the customer",
        "fieldType": "DECIMAL",
        "isRequired": false
    }
]

You can validate your response data format with the associated json schema.

⚠️ iAdvize can save up to 1024 characters in each field

Conversation panel app

Conversation panel apps extends the capabilities of the Desk by allowing our clients to embed their own apps in a dedicated panel.

General guidelines

A complete breakdown of our guidelines for Conversation Panel Apps can be found in our knowledge base.

App development

The apps that can be embedded in the Desk are web apps coded in any web compliant technology - static web page, dynamic web pages such as php or jsp generated, single page applications written in Angular or React, etc...

These apps will be embedded in an iframe element in the Desk, and the web server serving these apps must allow them to run in an iframe on the iAdvize domains: https://sd.iadvize.com or https://ha.iadvize.com. This is done by configuring the X-FRAME-OPTIONS header.

The app can communicate with the desk by using a library provided by iAdvize.

Please note that one iframe is created per conversation in order to keep a context for an app for each conversation. It is recommended to keep the app very lightweight and avoid heavy processing or streaming updates.

Library quick start

To use the library an app must include a javascript bundle in the html with the following code.

<script src="https://static.iadvize.com/conversation-panel-app-lib/2.9.0/idzcpa.umd.production.min.js"></script>

Then in the javascript code of the app the library can be used as follows.

window.idzCpa.init().then(client => {
    client.insertTextInComposeBox('Hello world!');
});

⚠️ CPAs available on the iAdvize iOS and Android apps must use the version 2.0.3 or greater.

API reference

idzCpa

idzCpa is a global variable used as the entry point of the CPA library.

init

function init(): Promise

The client is obtained via the idzCpa.init function that returns a Promise.

const clientPromise = idzCpa.init();
clientPromise.then(client => { / do something /});

Client context

client.context // => Context

type Context = {
    conversationId: string;
    projectId: string;
    channel: Channel;
    language: string;
}

// list of available channels:
enum Channel {
  AppleBusinessChat = 'APPLE_BUSINESS_CHAT',
  Call = 'CALL',
  Chat = 'CHAT',
  Facebook = 'FACEBOOK',
  FacebookBusinessOnMessenger = 'FACEBOOK_BUSINESS_ON_MESSENGER',
  GoogleBusinessMessages = 'GOOGLE_BUSINESS_MESSAGES',
  Instagram = 'INSTAGRAM',
  MobileApp = 'MOBILE_APP',
  Sms = 'SMS',
  Twitter = 'TWITTER',
  Video = 'VIDEO',
  Whatsapp = 'WHATSAPP',
}

The context property on the client returns the conversation context: conversation ID and project ID.

client.context.conversationId // => '5701a92f-a8e3-49ad-81dc-ac801171f799'
client.context.projectId // => '3103'
client.context.channel // => 'CHAT'
client.context.language // => 'fr'

List of commands available

Command	Description
insertTextInComposeBox	Allows the CPA to send some text to the active thread compose zone.
pushCardInConversationThread	Allows the CPA to send a card to the active conversation thread.
pushCardBundleInConversationThread	Allows the CPA to send a card carousel to the active conversation thread.
pushApplePayPaymentRequestInConversationThread	Allows the CPA to send an Apple Pay Payment request in the conversation thread.
getJWT	Allows the CPA to get a JWT token signed with the secret token defined in the connector of the CPA.

How to use each command

insertTextInComposeBox

Allows the CPA to send some text to the active thread compose zone.

Signature

function insertTextInComposeBox(value: string): void

⚠️ value field is required

Example

client.insertTextInComposeBox('Hello world!');

Result

insertTextInComposeBox

pushCardInConversationThread

Allows the CPA to send a card to the active conversation thread.

Signature

type Action = {
    type: 'LINK';
    title: string;
    url: string;
}

type Card = {
    title?: string;
    text?: string;
    actions: Action[],
    image?: {
        url: string;
        description: string;
    }
}

function pushCardInConversationThread(value: Card): void

⚠️ actions field is required and must contain at least one action of LINK type ⚠️ title, text and image fields are optional

Example

const card: Card = {
    title: "Card 1 title",
    text: "Card 1 description",
    actions: [
        {
          type: 'LINK',
          title: "Click here",
          url: "https://..."
        },
    ],
    image: {
        url: "https://...",
        description: "Image description add to alt img attribute",
    }
}

client.pushCardInConversationThread(card)

Result

pushCardInConversationThread

pushCardBundleInConversationThread

Allows the CPA to send a card carousel to the active conversation thread.

Signature

type Carousel = {
    title?: string;
    cards: Card[]; // See pushCardInConversationThread command for more information of Card type
}

function pushCardBundleInConversationThread(value: Carousel): void

⚠️ title field of Carousel is optional ⚠️ cards field of Carousel is required

Example

const card1: Card = {
    title: "Card 1 title",
    text: "Card 1 description",
    actions: [
        {
          type: "LINK",
          title: "Click here",
          url: "https://...",
        }
    ],
    image: {
        url: "https://...",
        description: "Image description add to alt img attribute"
    }
}

const card2: Card = {
    title: "Card 2 title",
    text: "Card 2 description",
    actions: [
        {
          type: "LINK",
          title: "Click here",
          url: "https://...",
        }
    ],
    image: {
        url: "https://...",
        description: "Image description add to alt img attribute"
    }
}

const carousel: Carousel = { cards: [ card1, card2 ] }

client.pushCardBundleInConversationThread(carousel)

Result

pushCardBundleInConversationThread

getJWT

• Allows the CPA to get a secured JWT token. This JWT is signed with the secret token defined in the connector of the CPA.

Signature

function getJWT(): Promise

Example

// use jwtToken on CPA for secure request
client.getJWT().then((jwtToken: string) => { / use JWT token / })

pushApplePayPaymentRequestInConversationThread

• Allows the CPA to send an Apple Pay Payment request to the active conversation thread.

• The CPA can only send an Apple Pay Payment request to a conversation from an Apple channel.

Signature

type ApplePayPaymentRequestType = {
    requestIdentifier: UUID;
    payment: ApplePayPaymentRequest;
    receivedMessage: ApplePayReceivedMessage;
}

// Detail for payment field type
type ApplePayPaymentRequest = {
  currencyCode: string;
  lineItems: PaymentItem[];
  requiredBillingContactFields: ApplePayContactField[];
  requiredShippingContactFields: ApplePayContactField[];
  shippingMethods: ShippingMethod[];
  total: PaymentItem;
}

type PaymentItem = {
  amount: string;
  label: string;
  type: ApplePayLineItemType;
};

enum ApplePayLineItemType {
  final,
  pending,
}

type ShippingMethod = {
  amount: string;
  detail: string;
  identifier: string;
  label: string;
};

enum ApplePayContactField {
  email = 'email',
  name = 'name',
  phone = 'phone',
  postalAddress = 'postalAddress',
  phoneticName = 'phoneticName',
}

// type for receivedMessage field
type ApplePayReceivedMessage = {
  type: 'CARD';
  data: CardType;
}

type CardType = {
  title?: string;
  text?: string;
  image?: CardImage;
  actions: LinkAction[];
};

type CardImage = {
  url: string;
  description: string;
};

type LinkAction = {
  type: 'LINK';
  title: string;
  url: string;
};

// Error
type ActionError = {
    message: string;
    details?: string[];
}

function pushApplePayPaymentRequestInConversationThread(applePayPaymentRequest: ApplePayPaymentRequestType): Promise

Note

If the request of payment is not sent, you may have an error in your request payload. To help you fix your payload, you can catch the error Promise: an ActionError is available with more details on what's happening.

More details about the ApplePayPaymentRequest type are provided in the official Apple developer documentation.

Example

const applePayPaymentRequest: ApplePayPaymentRequestType = {
    requestIdentifier: "83f86edb-XXXXX", // UUID
    payment: {
        currencyCode: "USD",
        lineItems: [
            {
                amount: "45",
                label: "Earpods",
                type: "final"
            },
            {
                amount: "955",
                label: "iPhone 12 mini",
                type: "final"
            }
        ],
        requiredBillingContactFields: ["email"],
        requiredShippingContactFields: ["email"],
        shippingMethods: [
            {
                amount: "10",
                detail: "Available within an hour",
                identifier: "in_store_pickup",
                label: "In-StorePickup"
            }
        ],
        total: {
            amount: "1000",
            label: "TOTAL",
            type: "final"
        }
    },
    receivedMessage: {
        type: "CARD",
        data: {
            title: "Please check this payment request",
            text: "Check this payment request and choose your shipping method",
            actions: [],
            style: "icon"
        }
    }
}

client.pushApplePayPaymentRequestInConversationThread(applePayPaymentRequest)
    .then(() => /* success apple pay payment request */)
    .catch((error: ActionError) =>
        /* error.message -> Error on command request */
        /* error.details (if exists) -> More details about the error if it exists */
    )

Result

• Message for an operator in the conversation thread when the CPA pushes an Apple Pay Payment Request:

applePaymentRequest

• Success payment:

applePaymentSuccess

• Failed payment:

applePaymentFailed

Style sheet

The library also provides a standalone stylesheet with CSS variables built-in to fit iAdvize's design guidelines.

An app can include it either in its HTML:

<link rel="stylesheet" src="https://static.iadvize.com/conversation-panel-app-lib/2.9.0/idzcpa.base.css">

Or as a top-level import inside a preprocessed-stylesheet:

@import 'https://static.iadvize.com/conversation-panel-app-lib/2.9.0/idzcpa.base.css';

A complete description of the provided variables can be found in our knowledge base.

Library Change log

Version	Description
1.0.0	Initial version with support for inserting text in the compose box via insertTextInComposeBox.
1.2.0	Add Conversation Panel App style sheet.
2.0.3	Add mobile apps support - from this version apps hosted in the iAdvize iOS and Android apps can use this library.
2.1.0	Return the conversation context in the client.
2.3.1	Support for inserting image type card and carousel of image type cards in the conversation thread via insertCardInConversationThread and insertCarouselInConversationThread
2.4.0	Replace command name and signature of each command: insertCardInConversationThread is replaced by pushCardInConversationThread and insertCarouselInConversationThread is replaced by pushCardBundleInConversationThread
2.6.0	Add new action getJWT to get a secured JWT token
2.7.0	Add new command pushApplePayPaymentRequestInConversationThread to send Apple Pay Payement request in the conversation thread
2.9.0	Add channel on init context

Configuration

Under the Plugins section create a Conversation Panel App and then edit the following fields:

App name

This is the name that will show in the toolbar button that starts your app. The name must be provided as a json object that contains a default name and then names for each language the app needs to support.

For instance {"default": "Orders", "EN": "Orders", "FR": "Commandes"}.

Icon name

The icon name refers to a set of predefined icons provided by iAdvize that will appear in the button that starts the app.

A live preview of each icon can be found here

Here is the list of available options by domain - the name must be entered in upper case.

Coupon
COUPON, DOLLAR, PERCENTAGE, TICKETS
Qualify lead
STAMP
Segmentation
TARGET, CARD
Delivery
DELIVERY, PACKAGE
Orders
ORDER, BOXES
Stock
STOCK, WAREHOUSE
Knowledge base
RECOMMENDATION, FILES, FOLDERS, SEARCH
User account
PROFILE, TARGETING, PROFILECARDS
Invoicing
INVOICING
Payment
PAYMENT
Shopping cart
SHOPPINGCART, SEARCHSHOPPINGCART
Product availability
BAGQUESTION, BAGSEARCH, PACKAGESEARCH
Stores
STORE
Location
LOCATION, POSITION, LOCATIONPIN
Assistance
TOOLS, TOOLING, HELP
Note
NOTE
Booking
BOOKING
Tags
TAG
Hotels & Services
HOTELS, HOTELOFFER, SERVICES
Generic/Random
NOTEBOOK, DIAMOND, BOUSSOLE, SHIRT, GEAR, FRAME45, TARGETING

Conversation panel app icons

iFrame URL

This field provides the URL that the Desk will use to start your app. It must be a public URL that can be targeted by the browser that runs the desk and available via https.

For instance: https://mycompany.com/ordersapp

Enable for operators

Check this checkbox to make the app available for operators.

Enable for experts

Check this checkbox to make the app available for ibbü experts.

Use authentication

Check this checkbox if your app requires a proof that the CPA is loaded within the desk or if you want the ID of the operator. You will receive a JWT in the url parameters that is signed with the secret token defined in the connector of the CPA. For instance a URL with a JWT will look like this:

https://app.iadvize.com/order.html?jwt=eyJ0eXAiOiJKV1QiLCJhbGciOiJIUzI1NiJ9...

The JWT can be decoded and validated by standard JWT libraries, for instance the jsonwebtoken library from auth0 https://github.com/auth0/node-jsonwebtoken

The code to decode a JWT looks like this:

const inputToken = "eyJ0eXAiOiJKV1QiLCJhbGciOiJIUzI1NiJ9...";
const secrettoken = '97db6bc85144af406a0e0040ad6f354b';
try {
const verifiedToken = jwt.verify(    inputToken,     secretToken,     { algorithms: ['HS256'] });// do something with verifiedToken// example token// {//     iss: 'iadvize',//     sub: '270586',//     aud: 'https://app.iadvize.com/order.html',//     exp: 1644502986,//     iat: 1644502926,//     email: '[e-mail]'// }
} catch(err) {
// handle the error by returning an unauthorised response
}

The JWT contains the following properties:

• iss the issuer is always iadvize

• sub the subject, it is the operator ID

• aud the audience is the url of the targeted CPA

• iat the issue time, unix timestamp in number of seconds

• exp the expiry time, unix timestamp in number of seconds

• email the operator email address

External bots

Bots are an important part of iAdvize integration ecosystem. That's why they have their own dedicated documentation.
